Specification:
|
Base Material:
|
Titanium (Gr1, Gr2)
|
|
Shape Of Base Material:
|
Bar / Wire
|
|
Working Current:
|
Max 5000 A/m2
|
|
Fluorine Ion Concentration:
|
Max 500 mg/L
|
|
Coating Material:
|
Platinum (purity 99.99%)
|
|
Rare Metal Concentration:
|
Min 21.48 g/L
|
|
Platinum Thickness:
|
0.5-10 μm
|
|
Temperature:
|
Max 80 ℃
|
|
PH Value:
|
1-12
|
Properties: application-specific design, this shape of anodes can be all platinized or partly platinized, tight adhesion between platinum layer and base titanium material, stable performance, energy saving, recoating possible, long service life.
Application: seawater, gold potassium cyanide + citric acid, plating line, pulse plating, cathodic protection, acidic & alkaline plating liquor.
