Base Material: Niobium
-
Shape: Mesh (customized)
-
Working Current: < 12000 A/㎡
-
Workmanship: Plating
-
Coating Material: Platinum (purity 99.99%)
-
Noble Metal Content: ≥ 21.48 g/㎡
-
Platinum Thickness: 0.5-15μm
-
Temperature: < 80℃
-
PH Value: 1-12
Properties: application-specific design, tight adhesion between platinum layer and base niobium material, stable performance, high current and low voltage, can be used for composite plating of ceramics.
Application: seawater, gold potassium cyanide + citric acid, horizontal plating, pulse plating, athode protection. It can be used in acidic or alkaline electroplating solution, also can be used in special electroplating solution which contains fluorinion.
